Product Details:
|
Machine Name: | Industrial Food Dehydrator | Usuage: | Commercial Food Dehydrator |
---|---|---|---|
Electric Heating Power: | 9 KW | Capacity: | 60 Kg |
Material: | Stainless Steel | Key Worlds: | Commercial Food Dehydrator |
High Light: | peanut butter production line,food smoking equipment |
Dehydro Presto Non Electric Best Commercial Mini Gas Solar Industrial Food Dehydrator
The dryer is suitable for drying of medicinal materials, food, tea, dry goods, flower tea, and grains.
1 Thermal insulation: The thermal insulation material is made of acid aluminum fiber, which has high insulation performance.
2 Intelligent constant temperature: It is easy to operate with intelligent computer, stable and accurate.
3 food grade stainless steel: the whole body is made of food grade stainless steel, which is not easy to damage and durable.
4 stainless steel tray: easy to remove for easy cleaning
Product advantages:
1 More money: The heat pump can effectively convert the heat energy in the air, and the drying cost is reduced by 30%.
2 More intelligent: PLC control panel can be used to control the temperature and humidity of the drying room according to the drying requirements of different materials. The operation is simple and the control is precise, which meets the requirements of various product drying processes.
3 drying effect is good: temperature adjustment, dehumidification operation at the same time, reasonable internal circulation wind design, so that the heat inside the drying room is evenly distributed to each corner, the product is fast drying, no loss, no odor, good quality, good selling.
4 Stable and reliable quality: ISO quality management system certification, independent research and development control system, stable performance and complete functions.
Technical Parameters
Model |
RXH-7C HG-60 |
RXH-14C HG-120 |
RXH-27C HG-240 |
RXH-41C HG-360 |
RXH-54C HG-480 |
Capacity | 60Kg | 120Kg | 240Kg | 360Kg | 480Kg |
Evaporation area | 7 sq.m. | 14 sq.m. | 27 sq.m. | 41 sq.m. | 54 sq.m. |
Number of trays | 24 | 48 | 96 | 144 | 192 |
Number of carts | 1 | 2 | 4 | 6 | 8 |
Dimension(mm) | 1470×1160×1980 | 2390×1160×1980 | 2390×2160×1980 | 3350×2160×1980 | 4380×2160×1980 |
Temperature range | Room Temperature - 150℃ | ||||
Electric heating power | 9 KW | 15 KW | 27 KW | 42 KW | 54 KW |
Steam consumption | 15kg/h | 23kg/h | 48kg/h | 72kg/h | 96kg/h |
Steam pressure | 0.2~0.8Mpa | ||||
Number of circulating fans | 1 | 1 | 2 | 3 | 4 |
Circulating fan performance |
3600m³/h/Each 0.45kW/Each |
||||
Drainage fan | 0.25kW/380V | 0.25kW/380V | 0.37kW/380V | 0.55kW/380V | 0.55kW/380V |
