Product Details:
|
| Keywords: | Meat Mixer | Name: | Vacuum Meat Tumbler |
|---|---|---|---|
| Dimension(mm): | 1200*1020*1640 | Material: | Stainless Steel |
| Rotate speed: | 2-20r/min | Volume: | 400L |
| High Light: | automatic sausage filling machine,industrial meat processing equipment |
||
Product description of Meat machine stainless vacuum tumbler blending machine meat food mixer:
The Vacuum Meat Tumbler has a wide range of applications, such as beef sauce processing, cooked food brine processing, chicken skewers, seafood, etc. For large factories, artificially marinating meat products is very laborious, and human strength is also limited. The marinated meat needs constant stirring to meet the marinating requirements. It can't meet the needs of production. This requires a vacuum tumbler, which can not only meet the requirements for rapid marinating, but also forward and reverse stirring, and marinate more uniformly. It can also meet the requirements of high-yield pickling, and the computer control panel is easy to operate.
Product Advantages:
1. This machine adopts high-quality stainless steel, round head has large rolling space, reasonable design, and low running noise.
2. The circular shape of the pulp leaves is unique, so that the marinade is evenly distributed without causing harm to the marinade, and the softness and appearance of the product are improved.
3. The waterproof computer controls the user to set the tumbler to automatically rotate forward, intermittent, deflate, and vacuum. Make the device truly realize the automatic breathing function.
4. The machine also has a frequency conversion function, so that the number of tumbles can be adjusted according to the process.
Main technical parameters of Meat machine stainless vacuum tumbler blending machine meat food mixer :
|
Model |
Volume |
Capcity Kg/tank |
Power |
Vacuum degree |
Rotate speed |
Dimension(mm) |
|
GR-100 |
100L |
50 |
1.85kw |
0.04-0.08mp |
2-20r/min |
1130*800*1100 |
|
GR-200 |
200L |
100 |
2.25kw |
0.04-0.08mp |
2-20r/min |
1200*1020*1640 |
|
GR-400 |
400L |
200 |
2.25kw |
0.04-0.08mp |
2-20r/min |
1200*1020*1640 |
|
GR-500 |
500L |
250 |
2.25kw |
0.04-0.08mp |
2-20r/min |
1460*1020*1640 |
|
GR-600 |
600L |
300 |
2.25kw |
0.04-0.08mp |
2-20r/min |
1500x1020x1640 |
|
GR-800 |
800L |
400 |
2.95kw |
0.04-0.08mp |
2-20r/min |
1880*1020*1640 |
|
GR-1000 |
1000L |
500 |
2.95kw |
0.04-0.08mp |
2-20r/min |
2000x1020x1640 |
|
GR-1200 |
1200L |
600 |
2.95kw |
0.04-0.08mp |
2-20r/min |
2100x1020x1720 |
Precautions:
1 When starting up, you should check whether each part is loose and whether you need to adjust the tightness of the chain.
2 Check whether the air tightness of the gas system is good, and keep it for half an hour after the vacuum is completed, and see if the vacuum gauge has changed and whether there is air leakage.
3 Check whether the reducer, vacuum pump, etc. are vibrated, abnormal noises, or shaken.
4 After entering the working state, follow the normal procedures to see if the equipment is abnormal.
