High Efficiency Pine Nut Dehulling Machine Good Mechanical Stability Easy To Install

Husking peeling huller pine nuts shelling nut dehulling machine sheller

Sheller product features and function description:

1.New structure, good mechanical stability and low noise;

2.Compact structure, easy to install and disassemble;

3.Peeling net, less granules, high precision, circulating shelling, 98% shelling rate, 96% completeness, self-adjusting according to material size, shelling, design, structure, circulation, shelling, undetachment and shelling Automatic, sieving, feeding, re-opening the shell, shells and separating the different material outlets.

This machine is suitable for large, medium and small processing plants and other enterprises.

Main technical parameters of Husking peeling huller pine nuts shelling nut dehulling machine sheller :

Product operation method:

1. First check whether the connections and transmission components are loose and there are no abnormalities.

2. The power supply and electrical device terminals are in good contact.

3. The gap of the unrolling roller has been adjusted before leaving the factory. Because the raw material size of the pine nuts is different, the size of the gap is adjusted according to the size of the fruit shape.

4. The size of the pine nuts that are taken off the pine cone is different. The size of the pine nuts is separated by 3-5 grades (or more). According to the graded raw materials, 3--5 shellers or a single sheller. .

5. Unloading roller clearance adjustment:

The shelling roll cover and the upper cover are movable, and the upper cover is opened to see the gap between the fixed roller and the moving roller. The fixing roller is fixed in the middle of the frame of the fixed roller shell, the bolt is loosened, and the pressure spring is arranged on both sides. The adjusting bolt, the inward adjustment gap becomes smaller, the outward adjustment gap becomes larger, the unwinding gap should be smaller than the pine nut diameter size by 1-1.5mm, and the bolt is fixed again after adjustment.

6. Because the pine nuts have different shell thicknesses, put a small amount of raw materials before starting the machine to see the shelling effect. By adjusting the size of the roller gap, the high integrity rate of the broken shell is achieved. The small fruit is unshelled and then removed again after the re-adjustment gap.

When the geared motor is used, pay attention to oil filling. All transmission parts should be inspected and tightened in time, and the residue residue should be cleaned in time for normal use.
